Stainless Steel Pressure Vessel

stainless-steel-pressure-vessels



Stainless Steel pressure vessel fabrication SFI designs and builds custom pressure vessels and reactors to meet our customer’s application requirements and per ASME Code. Because these vessels are used by practically every industry, we offer a wide variety of options to meet customer needs such as: Vessels built in the shop or on-site Stainless steel and other nickel based alloys Various material and weld finishes for tank interior and exterior Heating and cooling options; single or double wall construction Agitation systems for a variety of uses Tank supports (legs, lugs, skirts, saddles, flat pitched) Manways and fittings Components Sight glasses and lights CIP systems No foam inlets Downtubes Thermowells Outlet valves stainless steel pressure vessels manufacturers used stainless steel pressure vessels stainless steel pressure vessel laboratory stainless steel tanks and pressure vessels stainless steel pressure tanks for sale stainless steel high pressure vessels stainless steel vessels manufacturers

Type Of Blades Agitator

  • Anchor Type Stirrer
  • Propillker type Stirrer.
  • Pitched Blade Stirrer.
  • Ribbon Type Stirrer fro Reaction Vessel.

pressure vessel and heat exchanger manufacturer in ahmedabad

Technical Specificatiop of Limpet Reaction Vessel

Nominal Capacity (Lts.) Vessel Dimension Dia, (mm) x Straight Height (mm) Motor H.P Shaft Diameter (mm) Exchange Surface Area (sq. meters) Standard Design Pressure
Jacket Half – Tube
250 600 x 900 2.0 30 1.7 0.90
Inside -3 bar or vacuum
Jacket – 3 bar
Half Tube 6-Bar
500 800 x 1000 3.0 50 2.7 1.53
1000 1000 x 1400 5.0 50 4.4 2.75
2000 1200 x 1800 7.5 60 6.8 4.33
2500 1300 x 1900 10.0 70 7.8 4.96
3000 1400 x 2000 10.0 75 8.8 6.2
5000 1600 x 2500 15.0 100 12.6 8.1
6000 1750 x 2500 15.0 110 13.7 8.87
10000 2100 x 3000 25.0 115 19.8 12.85
